here to see an abbreviated list
of Generic Logic's customers.
Control Technologies Corporation
Command and Control
Technologies uses the GLG
Toolkit as the graphical engine for its Command
Toolkit products, and utilizes the GLG
Map Server for the GIS visualizations.
The CCT's newest product, C3I Surveillance Toolkit (C3iSTK), provides a Common Operating Picture for tactical surveillance and interdiction. Built with GLG's GIS and Map Server products, it provides real-time tracking and geo-referencing of targets of interest, as well as provide point and click control and monitoring for a network of sensor systems. With the help of GLG, C3iSTK is configurable with a wide array of maps, imagery, and terrain information, suitable for operation anywhere in the world.
and Control Technologies
Corporation selected the GLG Toolkit to be part of our Command and
Control Software Product Line because it provides the best overall
product value available on the market for real-time dynamic
visualization. A rich multi-platform feature-set is what originally
attracted us to GLG. But continuous product evolution and improvement,
as well as strong technical support, is what has kept our commitment to
the GLG product suite intact for over ten years."
on pictures to
see larger images.
RangeNet Toolkit. Click on pictures to see larger images.
C3I Surveillance Toolkit. Click on pictures to see larger images.
Fire Rescue Wind Monitoring. Click on pictures to see larger images.
Click here for more images by CCT
Click here to see the deployment images
BNF Technology Inc. is a global software company providing optimized solutions for operation and management of process plants. We have provided software solutions of DCS HMI, plant information, predictive analytics, performance and operation monitoring system for process plants since 2000.
With our patented and qualified solutions, we started our business servicing the nuclear power industry. We have expanded it to coal-fired, combined cycle power, seawater desalination and petrochemical plants. We have installed our solutions over 100 sites in Korea, USA, Malaysia and Kuwait. Utilizing our extensive expertise in process and factory automation, we are providing flexible and scalable solutions conforming to the highest quality standards, and at competitive pricing.
are utilizing the GLG Toolkit
to be part of our Monitoring and
Control Software Products because of its valuable Graphics Builder and
With GLG, we can freely make our own library of symbols for individual process industry customers, such as power, oil, gas, water... and deploy them in either desktop or web application to monitor and control production plants via real-time dynamic visualizations.
GLG has been improving month by month to bring more powerful features and strong technical support to us. That's why we have co-operated with the GLG product over 7 years”.
-Hoang Quoc Dung, BNF Technology Inc.
on pictures to see larger images.
These factory management and process monitoring screens were designed with the GLG Graphics Builder and updated with a real-time data feed in an application.
The main part of the control system is a process control iPC, which performs data exchange between PLCs and the supervisory database system. Other parts of the system are workstations for recipe handling, mixer program handling, analysis of the recordings, statistical analysis. f+p delivers ThinClient PCs for process visualization, operator panels, barcode printing and registration.
The GLG Toolkit is used as the graphics subsystem for displaying graphics, trends, data tables and alarm lists. The ease of integration of the GLG tools combined with the flexibility of the f+p software bus layout provided maximum benefits for rapid application design.
"We chose the GLG Toolkit because of the following advantages:
on pictures to see larger images.
The screens presented on this page were designed with the GLG Graphics Builder and updated with a real-time data feed from the iPC database.
BIS (Baltic Information Systems, Ltd.) is a software company specializing in development of safety and process monitoring systems for Nuclear Power plants.
The BIS's new product, BISMARC, is a universal process control and monitoring SCADA system that may be configured to fulfill almost any plant monitoring task. It utilizes client/server architecture with TCP/IP-based communication and multi-level redundancy for high reliability, where the server software performs the PLC data acquisition, data processing and archiving, while the client software is responsible for data visualization and handling user interaction. In a distributed system, each node may serve as a server and client simultaneously. BISMARC is currently available on the Linux platform.
The GLG Toolkit is used as the core engine for the graphics subsystem of the client application, the Plant Inspector. HMI drawings created in the GLG Graphics Builder are used as templates which are loaded into the Plant Inspector module at runtime. The Plant Inspector periodically updates trends and control points defined in the drawings with the real-time data values from PLCs. An operator can control plant devices by the means of buttons, toggles, switches, dials and other input objects in the drawings.
"We prefer the GLG Toolkit because of its flexible and powerful development environment, cross-platform design, Unicode and True Type font support, concise API, nice graphics and many other features. An excellent support from the Generic Logic team was invaluably helpful during the development process."
- Alexey Kolga, Baltic Information Systems
on pictures to see larger images.
Operator Interface for the Transportation Subsystem of the Radioactive Waste Treatment Facility. The drawings were designed with the GLG Builder and updated with real-time data from PLCs at run-time.
Operator Interface for the Radioactive Waste Treatment facility shows dynamic Valve Control and Pump Control popup panels used to control devices.
Automation provides software solutions and process control
chemical, tire and rubber industries. It also develops custom
applications for woodworking
machines and shoe making lines.
- Jiri Fillip, Filip
|Click on pictures
to see larger images.
Operator Interface for the Gas Furnace Flow Control monitors batching, mixing and weighing stages.
Sensis Corporation provides sensors and information technology to the world's militaries, civil aviation authorities, airports and airlines. Solutions include air and surface surveillance systems, sensor data interface equipment for integrating new and legacy surveillance and automation systems, vehicle tracking systems and aviation collaboration tools.
Using Generic Logic's technology, Sensis has created a web-based application suite called Aerobahn. Aerobahn enables airports, airlines and other key aviation constituencies to securely access, share, display and analyze the information contained within raw aviation data sources. The Aerobahn Traffic Display application, developed with the Generic Logic's GLG Toolkit allow users to visualize the location aircraft and airport vehicles overlaid on an airport map in real-time.
Control Products Unlimited, Inc. is a software solution integrator specializing in the movement of process information between plant floor, supervisory, and enterprise level systems. It has been a provider of SCADA products and solutions since 1990.
Control Products' product, CPUtilities, provides a complete software solution for OPC-based Supervisory Control and Data Acquisition, which uses the GLG Toolkit as a graphics subsystem.
Integrating the GLG Toolkit into Control Products' OPC based offering has introduced features that rival competitive packages in the market place. Training and support time has also been reduced through the implementation of solutions with graphical objects already familiar to plant personnel.
|Click on a picture
to see a larger image.
Providing an overview of water treatment and distribution, personnel can easily manage operations with visual feedback and point and click navigation to setpoint entry displays.
Global Factory provides software solutions that simplify the management of distributed manufacturing operations and significantly reduce their complexity and cost. It offers a new breed of enterprise software that is intuitive, easily integrated into existing environments and adaptive to changing requirements.
The GLG Toolkit underlies the graphic interface and provides the framework for a rich, integrated environment for business process design. Utilizing the Toolkit, Global Factory has developed a Flow Manager, a custom Java application that allows for interactive design of business processes. All main graphic components, such as application workspace, toolbars, buttons and shapes, were built completely in the Graphics Builder without any coding. The Toolkit's API provided all the necessary plumbing to bring these objects to life at runtime, and extend these objects via custom code. The result is an interactive, user-friendly experience.
The Flow Manager is used to design a business process via
dragging and connecting objects in a virtual workspace.
The diagram then creates and drives the backend processes
in the Global Factory system. Click on a picture to see a larger image.
GLG Toolkit is recognized for its power and flexibility by companies in
a wide variety of industries. An abbreviated list of Generic
Logic's customers includes:
Boeing North American
Lockheed Martin Space Systems
Lockheed Martin Astronautics
Command and Control Technologies
NASA Jet Propulsion Laboratory
NASA Spaceport Processing Systems
NASA Wallops Flight Facility
Kennedy Space Center
Spaceport Florida Authority
Mid Atlantic Regional Spaceport
Orbital Sciences Corporation
Honeywell Aerospace Electronic Systems
ATK Aerospace Systems Group
ASRC Aerospace Corporation
Netherlands National Aerospace Laboratory
Aerospace Industrial Development Corporation
Israel Aerospace Industries
Korea Aerospace Industries
Patria Aviation Oy
Cessna Aircraft Company
Naval Surface Warfare Center
Naval Undersea Warfare Center
US Air Force
US Department of Homeland Security
US Indian Health Service
US Government and DOD
UK Government Communications Headquarters
Royal Australian Air Force
Lockheed Martin Government Electronic Systems
Lockheed Martin Ocean, Radar & Sensor Systems
Lockheed Martin Engineering & Sciences
General Dynamics Advanced Information Systems
General Dynamics Land Systems
Thorpe SEEOP Corporation
TRW Space & Electronic Corp.
TRW Data Technologies Division
L-3 Communications Telemetry & Instrumentation
L-3 Communications Analytics Corporation
GE Government Systems, Inc
GE American Communications, Inc.
ITW Military GSE
Electric Boat Corp.
Singapore Defense Science and Technology Agency
Science and R&D
Thomas Jefferson National Accelerator Facility
Ericsson Radio Systems AB
Singapore Technologies Electronics
Carl Zeiss Microscopy Ltd.
Senergy Intellution Pvt.
Ultrasound Fluid Technologies
Patria Advanced Solutions
Patria New Technologies
DRS Test & Energy Management
Dekker Vacuum Technologies
India Centre for Development of Advanced Computing
ELF ANTAR France
Knowledge Engineering Pte Ltd
Financial Services and IT
Ernest & Yong
Computer Sciences Corporation
Tekmark Global Solutions
ASG Software Solutions
Austin Info Systems
Brainpool Consulting AB
Storage Content Analysis
Scandic Hotels AB
Esdotcom Support & Software Services
Massachusetts Institute of Technology
University of California Berkeley
Robotics and Intelligent Machines LaboratoryUniversity of Texas
Applied Research LaboratoriesUniversity of Rochester
Laboratory for Laser EnergeticsDrexel University
Electrical and Computer Engineering Dept.University of Wisconsin - Milwaukee
University of Michigan
Mental Health Research InstituteUniversity of Connecticut
Center for Biomedical Imaging TechnologyUniversity of Arkansas
Stevens Institute of Technology
Technical University of Denmark
Tokyo Metropolitan University
Aoyama Gakuin University, Tokio
University of Hong Kong
E-Business Technology InstituteVietnam Research Institute of Electronics
Korea Myong-Ji University
Department of Industrial EngineeringMexico's Center for Scientific Research
University of Salamanca, Spain
Department of Computer Science and Automatic ControlNational Distance Education University, Spain
Process Control and Monitoring
ABB Corporate Research
Honeywell Technology Solutions, Inc.
ADtranz Signal AB
Ford Motor Co.
UTC Fuel Cells
Alcan Aluminum Ltd
Alcan Primary Metal Group
BNF Technology, Korea
Barnett Control Systems
Global American Technology Corp.
Hyundai Heavy Industries
Machine Vision Products
Control Products Unlimited, Inc.
GSE Power Systems AB
UNISENSOR Sensorsysteme GmbH
Doosan Heavy Industries and Construction
Kyungbook Industry Co
China Oilfield Services
System Integrators and Consulting
Edgewater Computer Systems
Paranext Software GmbH
Service Expert GmbH
Noetic Software, Inc.
Tata Consultancy Services
Control Products Unlimited
Reinhold Seiz GmbH
Power and Utilities
GE Power Systems
Japan Atomic Energy Research Institute
Tokyo Electric Power Company
Engineering CenterCommonwealth Edison
Alabama Power Co.
Thermax Babcock & Wilcox Energy Solutions
Ontario Power Generation
Korea Hydro & Nuclear Power
Korea Atomic Energy Research Institute
GSE Power Systems AB
ÅF Industriteknik AB
City of Winnipeg
County of San Diego
Hungary Radioactive Waste Management
Western Australian Government Railways
Telecom and Networking
BT Global Services
FanSi Taiwan Corporation
PCCW Hong Kong
Portugal Telecom Inovaco SA
Logic if you want to resell, embed, or bundle GLG products or
technology with your own product to provide a value-added solution for
Logic was founded in 1994 to develop and
market the GLG Toolkit - a set of editors, libraries, tools and
components for creating and deploying dynamic graphical displays to
visualize and control real-time processes in variety of industries.
GLG Toolkit was developed as part of the
consulting activities from 1989 to 1994. It has grown from an in-house
consulting tool into a top-of-the-line real-time graphics and data
visualization product with various additional packages and deployment
options, from the Java version of the Toolkit to the Map Server module
with an integrated GIS functionality.
flexible component-based architecture of the Toolkit with open data
interface allows applications to use it as a add-on graphical interface
module, without locking them into a proprietary application framework,
which is the case with many other packages. The unique features of the
Toolkit, such as constraints, resource or tag-based data access and
infinite customization capability, provide application developers with
a powerful tool to handle the ever-increasing visualization needs of
Logic is continuing to increase the power
flexibility of its premier product - the GLG Toolkit, dedicating big
portion of the company resources to the development of new features and
adapting the Toolkit to
markets. The GLG Toolkit family of products supports a wide variety of
hardware platforms and software deployment options for Linux/Unix and
Windows, including the
Java version of the Toolkit, cross-platform support for OpenGL
rendering and AJAX Graphics Server for deploying on mobile devices.
Logic is constantly working on extending its
product offerings. The recent GIS Map Server product
compliments GLG Toolkit by offering GIS mapping functionality,
stand-alone or integrated into the Toolkit. A combination of the GIS
mapping functionality with the Toolkit's dynamic capabilities provides
new exciting opportunities for developing mission-critical applications.
Generic Logic is headquartered in Amherst, Massachusetts. Click here for contact information.
